Tok
125
Št. polov
2 P+E
Tip napetosti
AC
IP zaščita
IP67
Montaža
kotna
Vrsta produkta
vtičnica
Max. napetost (V)
250 V
Degree of protection (IP)
IP67
Number of poles
3
Material
Plastic
RAL-number
7035
Rated voltage (V)
200…250 Volt
IEC-amperage (A)
125
Connection system
Screwed terminal
Voltage acc. EN 60309-2
230 V (50+60 Hz) blue
Identification colour
Blue
Clock hour position (h)
6
Military model
No
Flange size vertical (mm)
114
Flange size horizontal (mm)
110
Angle of plug
Straight
Rated frequency (Hz)
50…60 Hertz
Drill hole distance horizontal (mm)
90
