Tok
16
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
1 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
1 NC
Krmilna napetost (V AC)
230 V AC
Built-in depth (mm)
43.5
Width in number of modular spacings
1
Number of contacts as normally open contact
1
Number of contacts as change-over contact
0
Number of contacts as normally closed contact
0
Mounting method
DIN rail
Frequency control voltage 1 (Hz)
50 Hertz
Voltage type of supply voltage
AC
Supply voltage (V)
250 Volt
Control voltage 1 (V)
230 Volt
Type of control voltage 1
AC
Max. switching current (cos phi = 0.6) (A)
2900
Function
Mechanical switch
Rated switch current (A)
16
Manual operation possible
Yes
Max. load fluorescent lamp (parallel compensated) (VA)
2900
Max. incandescent lamp load (W)
2900
Max. load fluorescent lamp (VA)
2900
Suitable for manual operation
Yes
