Tip
K11
Max. nazivni tok (A)
115
Max. nazivna moč pri 400 V AC (kW)
30
Št. polov
4 P
Vrsta stikala
grebenasto preklopno stikalo
Sestavni del
stikalo
Kot preklopa
60°
Nazivni tok (A)
115
Model
Reverser
Number of poles
4
Type of electrical connection of main circuit
Screw connection
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as change-over contact
0
Material housing
Other
Type of control element
Long turning handle
With 0 (off) position
Yes
With retraction in 0-position
No
Degree of protection (IP), front side
IP40
Complete device in housing
Yes
Suitable for front mounting 4-hole
Yes
Degree of protection (NEMA), front side
Other
Suitable for distribution board installation
No
Suitable for intermediate mounting
Yes
Suitable for ground mounting
No
