Colour outer sheath
Black
Oil resistant (acc. EN 60811-404)
Yes
Shape
Round
Material outer sheath
Other
Screen over stranding
None
Nominal cross section conductor (AWG) (1000 circular mil)
10
Torsion resistant
Yes
Outer diameter approx. (mm)
14
Screen over stranding element
None
Halogen free (acc. EN 60754-1/2)
No
Nominal cross section conductor (mm²)
1.5
Low temperature resistant (acc. EN 60811-504+505+506)
Yes
Core insulation material
Polyamide (PA)
Nominal voltage U0 (V)
250
Specification material outer sheath
Polyethylene (PE)
Specification core insulation
Polyethylene (PE)
AWG size
Other
Protective conductor
Yes
Nominal voltage U (V)
250
Stranding element
Triple
Cable width approx. (mm)
3000
Number of cores
3
Core identification
Colour
Suspension element
Other
Conductor category
Class 5 = flexible
Low smoke (acc. EN 61034-2)
No
Euro class acidity according to EN 13501-6
A1
Smoke development class according to EN 13501-6
S2
Reaction-to-fire class according to EN 13501-6
Eca
Flame retardant
In accordance with EN 60332-1-2
Euro class flaming droplets/particles according to EN 13501-6
D0
Conductor material
Copper
Halogen free according to EN IEC 60754-1
Yes
Halogen free according to EN IEC 60754-2
Yes
Halogen free according to EN IEC 60754-3
Yes
Armouring/reinforcement
None
With protective conductor
Yes
Material armouring
Copper
Low smoke according to EN IEC 61034-2
Yes
Conductor surface
Other
Protective barrier
Rubber - ethylene propylene rubber (EPR)
Max. conductor temperature (Degrees celsius)
65
Shape of conductor
Round
Drain wire
No
Screen
No
Core identification according to HD 308 S2
No
Flame retardant according to IEC 60332-1-2
Yes
Flame retardant according to IEC 60332-3-22 (Cat A)
No
Flame retardant according to IEC 60332-3-21 (Cat A F/R)
Yes
Flame retardant according to IEC 60332-3-24 (Cat C)
Yes
Flame retardant according to IEC 60332-3-23 (Cat B)
Yes
Flame retardant according to IEC 60332-3-25 (Cat D)
Yes
Cable geometry
Round
