Colour outer sheath
Black
Oil resistant (acc. EN 60811-404)
Yes
Shape
Round
Material outer sheath
Other
Screen over stranding
None
Nominal cross section conductor (AWG) (1000 circular mil)
10
Permitted cable outer temperature during assembling/handling (°C)
-16…65 °C
Torsion resistant
Yes
Outer diameter approx. (mm)
14
Permitted cable outer temperature after assembling without vibration (°C)
-10…60 °C
Screen over stranding element
None
Halogen free (acc. EN 60754-1/2)
Yes
Nominal cross section conductor (mm²)
1.5
Low temperature resistant (acc. EN 60811-504+505+506)
Yes
Core insulation material
Polyamide (PA)
Nominal voltage U0 (V)
250
Specification material outer sheath
Polyethylene (PE)
Specification core insulation
Polyethylene (PE)
Min. permitted bending radius, stationary application/permanent installation (mm)
45
Min. permitted bending radius, moving application/free movement (mm)
90
Min. permitted bending radius, moving application with forced guidance (mm)
180
AWG size
Other
Protective conductor
Yes
Nominal voltage U (V)
250
Stranding element
Triple
Cable width approx. (mm)
3000
Cable height approx. (mm)
0.7
Number of cores
3
Core identification
Colour
Suspension element
Other
Conductor category
Class 5 = flexible
Euro class acidity according to EN 13501-6
A1
Smoke development class according to EN 13501-6
S2
Reaction-to-fire class according to EN 13501-6
Eca
Euro class flaming droplets/particles according to EN 13501-6
D0
Conductor material
Copper
Halogen free according to EN IEC 60754-1
Yes
Halogen free according to EN IEC 60754-2
Yes
Halogen free according to EN IEC 60754-3
Yes
Armouring/reinforcement
None
With protective conductor
Yes
Material armouring
Copper
Low smoke according to EN IEC 61034-2
Yes
Conductor surface
Other
Protective barrier
Rubber - ethylene propylene rubber (EPR)
Max. conductor temperature (Degrees celsius)
65
Shape of conductor
Round
Drain wire
No
Screen
No
Core identification according to HD 308 S2
No
Flame retardant according to IEC 60332-1-2
Yes
Flame retardant according to IEC 60332-3-22 (Cat A)
No
Flame retardant according to IEC 60332-3-21 (Cat A F/R)
Yes
Flame retardant according to IEC 60332-3-24 (Cat C)
Yes
Flame retardant according to IEC 60332-3-23 (Cat B)
Yes
Flame retardant according to IEC 60332-3-25 (Cat D)
Yes
Cable geometry
Round
