Tip napetosti
AC
Napetost (V)
120 V
Sestavni del
I/O modul
Vrsta vhoda
digitalni
Tip modula
digitalni vhodni modul
Število I/O
16
Type of electric connection
Plug-in connection
Voltage type of supply voltage
AC
Height (mm)
100
Width (mm)
33
Depth (mm)
150
SIL according to IEC 61508
None
Performance level acc. EN ISO 13849-1
None
Explosion safety category for dust
None
Explosion safety category for gas
None
Appendant operation agent (Ex ia)
No
Appendant operation agent (Ex ib)
No
Suitable for safety functions
No
Number of digital outputs
0
Number of digital inputs
16
Redundancy
No
Supply voltage AC 50 Hz (V)
100…120 Volt
Supply voltage AC 60 Hz (V)
100…120 Volt
Power consumption (W)
3.8
Short-circuit protection, outputs available
No
Digital inputs configurable
No
Type of digital output
None
Digital outputs configurable
No
Type of voltage (input voltage)
AC
Type of output voltage
AC
Input current at signal 1 (mA)
5
Permitted voltage at output (V)
100…120 Volt
Permitted voltage at input (V)
100…120 Volt
Time delay at signal exchange (ms)
10…20 Millisecond
