Tip napetosti
DC
Napetost (V)
24 V
Sestavni del
I/O modul
Vrsta vhoda
digitalni
Tip modula
digitalni vhodno-izhodni modul
Število I/O
16
Type of electric connection
Plug-in connection
Voltage type of supply voltage
DC
Height (mm)
100
Width (mm)
33
Depth (mm)
150
SIL according to IEC 61508
None
Performance level acc. EN ISO 13849-1
None
Explosion safety category for dust
None
Explosion safety category for gas
None
Appendant operation agent (Ex ia)
No
Appendant operation agent (Ex ib)
No
Suitable for safety functions
No
Supply voltage DC (V)
3.3 Volt
Number of digital outputs
8
Number of digital inputs
8
Category according to EN 954-1
1
Redundancy
No
Power consumption (W)
3.1
Output current (A)
2
Short-circuit protection, outputs available
Yes
Digital inputs configurable
Yes
Type of digital output
Relay
Digital outputs configurable
Yes
Type of voltage (input voltage)
DC
Type of output voltage
DC
Input current at signal 1 (mA)
3.5
Permitted voltage at output (V)
24 Volt
Permitted voltage at input (V)
24 Volt
Time delay at signal exchange (ms)
4…7 Millisecond
