Tip
ZB4
Premer (mm)
22 mm
Sestavni del
glava tipke
Vrsta produkta
tipka
Barva
črna
Oznaka na glavi
ne
Tip upravljanja
povratna vzmet
Možnost osvetlitve
ne
Pritrdilka
ZB4BZ009
Nosilec legende
ZBZ33
Degree of protection (IP)
IP66
Degree of protection (NEMA)
Other
With front ring
Yes
With retraction in 0-position
Yes
Colour front ring
Chrome
Number of switch positions
2
Material front ring
Metal
Rated operation current Ie at AC-21, 400 V (A)
10
Number of normally open contacts per actuation direction
0
Analogue output signal configurable
No
Joy stick length (mm)
107
Coder
No
Number of make-and-break contacts per direction
0
Centre mounting, hole diameter (mm)
22.5
Number of actuation directions
2
Locking in 0-position
No
Number of normally closed contacts per actuation direction
0
Number of switch levels
0
