Tip
XB5
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
1 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
0 NC
Tip napetosti
DC
Premer (mm)
22 mm
Napetost (V)
24 V
Vrsta produkta
časovnik
Oznaka na glavi
ne
Tip upravljanja
zasuk
Možnost osvetlitve
ne
Degree of protection (IP)
IP65
Rated current (A)
0.001
Number of contacts as normally open contact
0
Number of contacts as change-over contact
0
Number of contacts as normally closed contact
0
Type of electric connection
Screw connection
Model
Electronic
Mounting method
Other
Voltage type for actuating
DC
Rated control supply voltage Us at DC (V)
24 Volt
Colour
Other
Nominal voltage (V)
24
Height (mm)
62
Width (mm)
29
Depth (mm)
29
Halogen free
No
Transparent
Yes
Material
Plastic
Surface finishing
Glossy
Material quality
Other
Surface protection
Untreated
Nominal current (A)
0.2
Complete with socket
No
Number of outputs, delayed, normally open contact
0
Number of outputs, delayed, normally closed contact
0
Function delay on de-energization
Yes
Pluggable on auxiliary contact block
No
Clock function, starting with pause, variable
No
Clock function, starting with pulse, variable
No
Number of outputs, undelayed, change-over contact
0
Number of outputs, undelayed, normally open contact
0
Number of outputs, undelayed, normally closed contact
0
Function floating contact on de-energization
No
Function pulse shaping
No
Function delay-on energization
Yes
Number of outputs, delayed, change-over contact
0
With semiconductor output
Yes
Suitable for DIN rail (top hat rail) mounting
No
Function floating contact on energization
No
Outputs, reversible delayed/undelayed
No
Function star-delta
No
Function flashing, starting with pause, fixed time
Yes
Function flashing, starting with pulse, fixed time
No
Remote operation possible
No
Suitable for remote control
No
Time range (s)
3…60 Second
Suitable for degree of protection (IP)
IP65
Time setting (min)
3…60 Minute
Assembly arrangement
Other
Min. depth of built-in installation box (mm)
69
Number of modules (module system)
1
Operating voltage at DC (V)
16.8…31.2 Volt
Voltage type (operating voltage)
DC
Material of contact surface
Other
Material of contact insert
Other
Material contact
Other
IFTTT support available
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Suitable for front mounting
Yes
Max. starting current (Ampere)
10
