Kratkostična zmogljivost
100 kA
Max. nazivni tok (A)
160
Št. polov
3 P
Tip napetosti
DC
Nazivni tok (A)
160
Tip zaščite
brez
Serija
NSX
Degree of protection (IP)
IP3X
Number of poles
3
Type of electrical connection of main circuit
Screw connection
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as change-over contact
0
Type of control element
Toggle
With integrated under voltage release
No
Device construction
Built-in device fixed built-in technique
Rated voltage (V)
750 Volt
Suitable for DIN rail (top hat rail) mounting
No
Motor drive integrated
No
Motor drive optional
Yes
Complete device with protection unit
No
With under voltage release
No
DIN rail (top hat rail) mounting optional
Yes
With switched-off indicator
Yes
Position of connection for main current circuit
Front side
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz (kA)
100
Integrated earth fault protection
No
Power loss (Watt)
27.6
